wood pellet mill

Shandong Leader Machinery Co.,ltd. has finished hundreds of successful projects over the years: peanut oil, soybean oil, rapeseed oil, cottonseed oil, sunflower oil, sesame oil, animal oil,grape seed oil, acer truncatum oil, peony seed oil, walnut oil, hemp seed oil, pine oil, tea seed oil, papaya oil, milk thistle seed, and other special type oil.We have independent import and export department. Our equipment has been successfully exported to more than 100 countries: Russia, Australia, India, Afghanistan, Cameroon,and so on.

Specifications

wood pellet mill
high quality ring die, press roller, advanced technology ect.

Wood Pellet Mill

Specifications: 10T per hour process capacity

MUZL42-138 Pellet machine is a novel granular-feed press produced by our company.This machine has features of high quality ring die, press roller, advanced technology ect.,and which’s drive system adops the double motor triangle belt drive in the advantages of less ground demand,even stress, simple structure, convenient operation maintenance. This machine can also transform motor and ring mode to adapt the needs of different production capacity and specifications to obtain an ideal technical and economic benefit.

1.Component

Mainly composed by three major part: feeder,modulator and pelleter.(see above figure)

Through adjusting and coordinating the feed rate, curing degree and production capacity, can obtain result of granulating.

2.Main technical parameters: MUZL420

3.Technical parameters

Main motor power	45(55)KWX2
Feeder motor	1.5KW
Modulator motor	7.5KW
production capacity	10t.p.h
Hollow spindle speed	335r.p.m
Ring die effective size	φ420x138
outline dimension LxBxH(mm)	2386x2150x2175(mm)

4.Structural features

(1) Ring die is adopted precision machined high chromium alloy steel forgings, and applied vacuum heat treatment process with high finish holes and long service life

(2) High strength cast iron cast the machine frame to ensure the rotation safe ,stable and reliable.

(3) The alloy structure forging main shaft, has good strength and toughness.

(4) The flywheel effect of the cast steel hollow main shaft with large pulley, make the granulating work smooth, low noise, little vibration.

(5) The Feeder, Modulator and Granulating chamber are all using stainless steel material,and the independent cutter mechanism is adopted set piece of structure for durable.

(6) Bolted machine enclosure is easy disassembly and maintenance.

(7) When running, roller can always get good lubrication through lubrication piping.

(8) Granulating machine equipped with ring die lifting mechanism.

(9) The three parts of the complete machine can be Sold separately.

KYW30/35 Pellet machine

1. performance characteristics

This machine is the improvement products of KYW30/35 granular-feed press, which main features are as follow: the parts of feed,tempering,granulating, lubrication are all using independent drive; components in contact with material and steam are all made of stainless steel; feed screw using alternating current magneto stepless speed regulation drive to freely adjust the feed flow rate according to the main engine load; and has the devices of automatic lubrication, strongremoving iron, automatically measuring temperature and mechanical and electrical co-insurance. The whole machine has rational construction and and advancedtechnology,with the advantages of High output, less power consumption, easy operation, good economical benefit.

2.Purpose and Scope of application:

This machine is mainly used for pressing pellet feed to small and medium compound feed factory on the annual output of 8000/12000 tons, which also be applied to press pellet feed for all kinds of farms tomechanized raise chickens, ducks, fish and pigs.

3.Main specifications and technical parameters:

Progect		Unit	KYW30A	KYW35A
Output		t/h	1—4	3—5
Stamper inner diameter		mm	300	350
press roller outer diameter		mm	130	148
Eccentric shaft eccentricity		mm	9	12
out granule hole diameter		mm	φ2.5—φ12	φ2.5—φ12
Stamper rotate speed		r.p.m	339	244
Feeder rotate speed		r.p.m	13--130	13—130
conditioner rotate speed		r.p.m	300	375
Power configuration	Main motor	Kw	37(Y225S-4)	55(Y250M-4)
	conditioner motor	Kw	1.5(Y100L-6)	2.2(Y112M-6)
	feeder motor	Kw	0.75(JZTY12-4)	1.1(JZTY21-4)
	Dry oil pump motor	Kw	0.37	0.37
Outline size(LxWxH)		mm	1950X750X1566	2150X860X1780
Weight		Kg	1500	2000

1.Our technical content has reached international advanced level with strong technology supporting of LD University of Technology.

2.All productions management are strictly performed in accordance with the 6S and ISO quality assurance requirements;

3.Our selection of materials for products and production processes are in national and industry standards.

Pls contact us to learn more about us and our equipment at http://hnhtly.en.alibaba.com or call me at 0086-15093119367

Main Structure of wood pellet mill:
This combined oil expeller is composed by four parts: feeder, press chamber, electrical control panel
and vacuum filter drum. The heating system is inside the press cage. The filtering drum is vacuum
filter with sight glass.
AAA1

The oil sight glass can help user to control the speed of oil clearing process. Integrated oil press
machine is an ideal choice for those who do business in the country market or who
run a small or medium oil mill in city.

AAA2

wood pellet mill is patented production in wood pellet mill, adopts the most advanced technology, product quality sunflower seeds oil.
The refining section includes sunflower seeds crude oil ,phosphoric acid degum, washed dry, dewax, decolorizing, physical deacidification deodorization, dewaxing, refined oil.

AAA3

If you have any demand about microwave drying equipment and edible oil refining equipment, pls feel free contact us any time.
